BestCode Next Series 8 Technical Manual October 2022 Page 149 of 290
4. Cut away the old valve wires and solder
on the new valve.
Wire colors for the Printhead Valve are
White/Red/Orange stripe and
White/Green/Yellow stripe.
There is no wire polarity.
5. Make sure the Valve gasket is in place
6. Reinstall the valve.
