BestCode NExT 88SHS - Firmware Loading Process

BestCode Next Series 8 Technical Manual October 2022 Page 202 of 290
Step 4:
Simultaneously start a 60
seconds timer and open the
printhead valve.
This will begin filling the
graduated cylinder with ink.
Step 5:
When the time reaches 60 seconds, disable the Printhead valve.
Step 6:
Measure the Ink in the Graduated Cylinder
For all models, there should be atleast 55ml of Ink or
about 2oz in the cylinder.
Less than this indicates a flow restriction to the drop
generator that must be resolved.
