BestCode Next Series 8 Technical Manual October 2022 Page 35 of 290
Font
Font Size
Sets the height of the font currently
selected. This value cannot exceed the
Template Size
3,5,7,9,12,16,19,25,32
Template
Sets the maximum printed drop height
of the message
1*3,1*5,1*7,1*9,1*12,1*16,1*19,
1*25,1*32,2*7,2*9,2*12,3*7,4*7,5*5
Bold
Each settings increases the width of
the selected field by adding more
printed drops. Makes darker print.
0-9
Gap
Increases the space between
characters in the selected field.
0-9
Rotation
Rotates the print on the screen
Normal, Mirror, Flip, Mirror Flip, Tower
CCW, Tower CW
Auto-Numerals
Changes the number set used for the
selected Autocode field.
Multi-language options.
Settings
Width
Increases or decreases the length of
the message by stretching or shirnking
the print
0-1000
Height
Increases or decreases the height of
the print by increasing or decreasing
the strength of the high voltage field in
the printhead.
0-10
Delay
Increases or decreases the time
between receiving a print trigger and
print occuring.
0-4,000,000,000
Rotation
Rotates the direction that the print
appears on the product
Normal, Mirror, Flip, Mirror Flip
Speed
Used to increase the maximum print speed.
Fast
Best Quality
Faster
Faster than Fast, Good Quality
Fastest
Higher Speed, OK Quality
Ultra-Fast
Fastest Print, Readable Code
New
Opens the New Field screen for adding more fields into the Message Editor.
Copy
Creates a duplicate of the selected field
Delete
Deletes the selected field
