Big Backyard F23475 - Page 14

S7
(62) Pan Screw #12 x 2" (9264620)
S0
(135) Truss Screw #8 x 7/8" (9229505)
S1
(84) Wood Screw #8 x 1-1/8" (9260514)
S3
(136) Wood Screw #8 x 2-1/2" (9260522)
S4
(35) Wood Screw #8 x 3" (9260530)
HARDWARE ID (Actual Size)
(5) Corner Brace
(12)
Hole Plug
(9201100)
(Pkg of 2)
w/ hardware
(9329900)
PB1
CB2
PB4
(9283200)
(2) Pan Bolt 1/4 x 1ǫ" (9274216)
(42) Pan Bolt 1/4 x 3/4" (9274203)
1/4" Lock Nut
(56)
Bushing Spacer
(9300510)
GL5½
(2)
CB1
S2
(318) Wood Screw #8 x 1-1/2" (9260512)
LS1
(16) Lag Screw 1/4 x 1½" - 1/4" Flat Washer
9262212
LS3
(22) Lag Screw 1/4 x 3" - 1/4" Flat Washer
9262230
(14)
5/16" T-Nut
(9285300)
S6
(8) Pan Screw #12 x 1" (9264610)
(38)
5/16" Flat Washer
(9251300)
(14)
5/16" Lock Washer
(9253300)
(64)
1/4" T-Nut
(9285200)
(118)
1/4" Flat Washer
(9251200)
(64)
1/4" Lock Washer
(9253200)
(12)
5/16" Lock Nut
(9283300)
G4
(2) Hex Bolt 5/16 x 4"
5/16" Lock Washer - 5/16" Flat Washer - 5/16" T-Nut
9277340
(4) Hex Bolt 5/16 x 1-1/2"
5/16" Lock Washer - 5/16" Flat Washer - 5/16" T-Nut
G1
9277312
(8) Hex Bolt 5/16 x 4-1/2"
5/16" Lock Washer - 5/16" Flat Washer - 5/16" T-Nut
G5
9277342
(4) Hex Bolt 5/16 x 5½"
5/16" Flat Washer (X2) - 5/16" Lock Nut
9277360
LS2
(2) Lag Screw 1/4 x 2½" - 1/4" Flat Washer
9262222
(2) Carriage Bolt 1/4 x 2" (9279220)
(10) Carriage Bolt 1/4 x 1½" (9279212)
