H.
SL Block in next step.
Drill hole on bottom of Exit for mounting
Bolt Exit rail here
E
: Remove Clamp Ring from Elbow and
assemble to Exit. Align holes on left and
tighten. Drill last hole in Exit using the holes
in the Clamp Ring as a guide.
through
previously
drilled holes.
Align previously
drilled hole.
Drill 1/4" hole
Location of Clamp Ring Filler,
when exit is assembled to
elbow in next step #5
Drill 1/4"
thru-hole
1/4" Lock Nut
1/4" Flat Washer
CB2
Bushing Spacer
Exit Assembly (continued)STEP 37B
rails and tighten.
through previously drilled holes on both side
: To safely secure Exit. Insert bolt assembly
G
align tighten Clamp Ring.
and Exit while inserting Clamp Ring Filler, re-
: Loosen Clamp Ring; re-assemble to Elbow
F
53
