STEP 27 Attach Ladder
S2
Wood Parts
w/ hardware (pkg of 2)
1X Corner Brace
1/4 x 1½” lag screws (with flat washer) per hand grip.
2X Hand Grip
H4
(LS1)
(C4)
Lag Screw 1/4 x 1½"
Ground Access 1 x 6 x 37¾"
Center Divider using 2 Post and 1 to the1 Hand Grip to the
(B18)
2X
2X
E181X
Hardware
Hex Bolt 1/4 x 4"
Wood Screw #8 x 1½"
4X
1X Assembled Access Ladder
A
: In the opening across from the Rock Wall attach the Access Ladder
to
(B20)
Back Floor using 2
(H4)
1/4 x 4” hex bolts (with flat washer,
lock washer and t-nut).
B
: Attach
(E18)
Ground Access to
(C8)
Ground Front Back using 2
Corner Braces with hardware.
C
: Attach
(E18)
Ground Access to the Access Ladder using 2
(S2)
#8
x 1½” wood screws.
D
: Pre-drill using a 1/8” drill bit by using hand grips as a guide. Attach
LS1
Corner Brace
w/ hardware
X2
S2
C4
B11
Hand Grips
C8
2 per Hand Grip
LS1
B20
E18
H4
B18
42
To Next Page
