Big Backyard F23475 - STEP 38 Attach Slide to Fort

#4
#3
#6
Exit Assembly
Parts
Seam of Mid Elbow between #2 and #3 of Lower
of Mid Elbow.
1X
#2
Elbow. Align Seam of Clamp Ring between #1 and #2
3X Assembled Clamp Rings
Assembled Elbows2X
A
: Assemble Upper Elbow to Flange using Clamp
Ring. The seam of Flange and seam of Clamp Ring
should be between #6 and #7 of the Upper Elbow and
then tighten Clamp Ring Bolts.
B
: Assemble Mid Elbow to Upper Elbow. Align seam
of Upper Elbow between #3 and #4 of Mid Elbow.
Align seam of clamp ring with seam of Upper Elbow.
Tighten Clamp Ring Bolts.
C
: Attach Exit Assembly with last Clamp Ring. Align
#3
STEP 38 Attach Slide to Fort
#1
#2
Lower Elbow
Mid Elbow
Use Help
TNR Slide Exit
Upper Elbow
Flange
#7
54
