10½"
A2
STEP 31 Attach Ground Stakes
S3
X6
X12
(2 per
A2
)
Make sure the Stakes are tight and secure.
Ground Stakes 2 x 2 x 14"
Do not use concrete to anchor Ground Stakes.
Ground Stakes to the 6 places specified on the
fort. It is important they are placed as shown. Make sure to drive
#8 x 2½” wood screws per stake.
Wood Parts
the Ground Stakes 10½” into the ground before fastening with 2
(S3)
6X
Hardware
12X Wood Screw #8 x 2½"S3
GROUND WIRING, CABLES, OR GAS LINES
12X Hole Plug
IF YOU DON'T CHECK FIRST FOR UNDER-
WARNING! DIGGING CAN BE DANGEROUS,
A2
A
: Attach 6
(A2)
B
: Inspect for open
3/8" holes. Insert
Hole Plugs into all
unused holes.
46
