Big Backyard F23475 - STEP 22 Attach Roof

D
: Attach
(E32)
Lower Roof Support to
(E36)
S21X
wood screw.
Wood Screw #8 x 1½"
Use Help
1X Corner Brace
w/ hardware (pkg of 2)
S4 Wood Screw #8 x 3"
8X
Hardware
1X
Assembled Roof
Wood Parts
Soffit using 2 Corner
Braces with included hardware.
A
: With the assistance of a helper lift Roof onto the fort as shown below.
Make sure roof is level.
B
: Using 2
(S4)
#8 x 3” wood screws per corner attach roof to
(E16)
SW
Roof Side and
(D9)
Slide Top.
C
: Attach
(E31)
Short Roof Joist to
(D9)
SL Top using 1
(S2)
#8 x 1½”
D9
STEP 22 Attach Roof
S2
E31
w/ hardware
Corner Braces
S4
S4
S4
E16 Roof
Assembled
D9
S4
E32
