1.4 Type plate
The type plate sticks to the left side of the chamber, bottom right-hand.
Figure 1: Type plate (example KBW 240 regular chamber)
Indications of the type plate (example)
Information
BINDER
Manufacturer: BINDER GmbH
KBW 240
Model designation
Growth chamber
Device name
Built
2017
Serial no. of the chamber
Serial No.
00000000000000
Year of construction
Nominal temperature
70 °C / 158 °F
Nominal temperature
IP protection
20
IP type of protection acc. to standard EN 60529
Temp. safety device DIN 12880 Temperature safety device acc. to standard DIN
12880:2007
Class
3.1
Class of temperature safety device
Art. No.
9020-0338
Art. no. of the chamber
Project No.
---
Optional: Special application acc. to project no.
1,40 kW
Nominal power
6,1 A
Nominal current
200-230 V / 50 Hz
Nominal voltage range +/-10%
at the indicated power frequency
1 N ~
Current type
Max. operating pressure 15 bar
Max operating pressure in the refrigerating system
(15 bar / 218 PSI)
R 134A - 0,27 kg
Refrigerant type and filling weight
Contains fluorinated greenhouse gases covered by the Kyoto Protocol
Symbol on the type plate
Information
CE conformity marking
Electrical and electronic equipment manufactured / placed on the mar-
ket in the EC after 13 August 2005 and be disposed of in separate col-
lection according to Directive 2012/19/EU on waste electrical and elec-
tronic equipment (WEEE).
GS mark of conformity of the “Deutsche Gesetzliche Unfallversicher-
ung e.V. (DGUV), Prüf- und Zertifizierungsstelle Nahrungsmittel und
Verpackung im DGUV Test“ (German Social Accident Insurance
(DGUV), Testing and Certification Body for Foodstuffs and Packaging
Industry in DGUV Test).
The chamber is certified according to Customs Union Technical Regu-
lation (CU TR) for Russia, Belarus and Kazakhstan.
Nominal temp.
70 °C
1,40 kW / 6,1 A
Max. operating pressure 15 bar
158 °F
200-230 V / 50 Hz
R 134A – 0,27 kg
IP protection
20
Contains fluorinated
Safety device
DIN 12880
1 N ~
greenhouse gases covered
Class
3.1
by the Kyoto Protocol
Art. No.
9020-0338
Project No.
Built
2017
Growth chamber
BINDER GmbH
Im Mittleren Ösch 5
78532 Tuttlingen / Germany
www.binder-world.com
KBW 240
E6
Serial No. 00000000000000
Made in Germany
