14.5 Network and communication
For these settings at least the “Admin” authorization level is required.
14.5.1 Serial interfaces
The chamber is optionally equipped with a serial RS485 interface.
This menu allows to configure the communication parameters of the RS485 interface.
The device address is required to recognize chambers with this interface type in a network, e.g. when
connecting it to the optional communication software BINDER APT-COM™ 3 DataControlSystem (chap.
19.1). In this case do not change the other parameters.
Path: Main menu > Settings > Serial interfaces
“Serial interfaces” submenu.
Select the desired setting in the field “Baud
rate”.
“Serial interfaces” submenu.
Select the desired setting in the field “Data
format”.
“Serial interfaces” submenu.
Select the field “Minimum response time”
“Minimum response time” entry menu.
Enter the desired minimum response time
and press the Confirm icon.
