Binder CB Series - Page 56

CB / CB-UL, CBF / CBF-UL (E7) 01/2022 Page 56/199
Figure 30: Inserting the partition wall
Then slide the partition towards the back of the chamber until it clicks into place.
Rear Rear
Figure 31: Partition wall, size 56, assembled Figure 32: Partition wall, size 170 / 260, assembled
Figure 33: Shelf holder with inserted partition walls (example, size 170)
