53
4. Select a mode.
5. Select a side: Left, Right, or None.
6. Position the dynamometer attachment to the Toward position and select the Toward
button to record the position. Arrows will display at the selected Toward limit.
7. Position the dynamometer attachment to the Away position and select the Away button
to record the position. Arrows will display at the Away limit and the ROM will be shaded
in.
NOTE: To start over, select the Clear Limits icon.
NOTE: It is recommended to set the Toward limit first, and then the Away limit. If the
order is reversed, you will still be able to select the Set Position icon and progress to an
activity.
8. Select the Set Position icon.
NOTE: The Anatomical Reference refers to the starting position of the joint and will
change based on the joint selected.
9. Select the Next icon to begin your activity.
