8. Specifications and Certifications
Clinical Data Station:
PC with Windows 10 Enterprise LTSC
Biodex Advantage BX™ Software
22” flat panel touchscreen with integrated speakers
Attachments for Ankle, Knee, Shoulder, Elbow, Wrist and Hip (850-000)
Calibration Kit
Operating space: 64 square feet (6 square meters) (850-000, 852-000)
Certification:
IEC 60601-1:2005 (Third Edition) + CORR. 1:2006 + CORR. 2:2007 + A1:2012 (or IEC 60601-
1: 2012 reprint)
ANSI/AAMI ES60601-1:2005+A1:2012+C1:2009+A2:2010.
CAN/CSA C22.2 No. 60601-1:14
IEC 60601-1-2:2014
Electrical Requirements:
230VAC, 50-60Hz, 8 amps
Requires 20A isolated dedicated service
Hospital Grade Plug must be rated for 230VAC; 15 amps minimum
North American Units supplied with NEMA 6-20P
Equipment should have means to isolate its circuits electrically from the supply mains on all
poles, simultaneously.
Mechanical Specifications: Total Weight: 1350 pounds (612kg)
Physical Dimensions:
CDS Cart: 25” wide, 19” deep, 41" high (64 × 48 × 104cm)
T-Base & Chair: 52” wide, 65” deep, 60” high (132 × 165 × 152cm)
Attachment Cart: 33” wide, 20” deep, 40” high (85 × 51 × 102cm)
Dynamometer Performance Specifications:
Concentric speed up to 500 deg/sec
Eccentric speed up to 300 deg/sec
Concentric torque up to 500 ft-lb (680 Nm)
Eccentric torque up to 400 ft-lb (542 Nm)
Torque accuracy is +/-1% of full scale (500 ft-lbs [680Nm])
Torque is factory calibrated
Position range is 330°
Position accuracy is + / -1° of rotation
Torque verification fixture is 50 ft-lbs +/- 0.5 ft-lbs (68Nm +/- .68Nm)
Environmental Condition:
Operating Temperature: 10°C to 37°C (50°F to 100°F).
Transport & Storage Temperature: -20° C to 70° C (-4° F to 158° F).
Relative Humidity: 20% to 90% non-condensing.
Atmospheric Pressure: Sea Level 101kpa (14.7psi) to 10,000 feet, 69 kpa (10.1 psi)
NOTE: Specifications and Certifications continued on the next page.
