Table of Scale Range and Factors
Scaling Option
Range
Scale Factor
Velocity:
0 – 512 deg/sec
-521 to +512 deg/sec
9.8 mV per deg/sec
0 – 256 deg/sec
-256 to +256 deg/sec
19.5 mV per deg/sec
0 – 128 deg/sec
-128 to +128 deg/sec
39.1 mV per deg/sec
1 – 64 deg/sec
-64 to +64 deg/sec
78.1 mV per deg/sec
0 – 32 deg/sec
-32 to +32 deg/sec
156.3 mV per deg/sec
Toque:
0 – 512 ft-lb (696 Nm)
-521 to +512 ft-lb (-708 to +696 Nm)
9.8 mV per ft-lb
0 – 256 ft-lb (348 Nm)
-256 to +256 ft-lb (-348 to +348 Nm)
19.5 mV per ft-lb
0 – 128 ft-lb (174 Nm)
-128 to +128 ft-lb (-174 to +174 Nm)
39.1 mV per ft-lb
1 – 64 ft-lb (87 Nm)
-64 to +64 ft-lb (-87 to +87 Nm)
78.1 mV per ft-lb
0 – 32 ft-lb (43.5 Nm)
-32 to +32 ft-lb (-43.5 to 43.5 Nm)
156.3 mV per ft-lb
Position:
Full scale (~ 306 degrees)
0 to 306 degrees
29.2 mV per degree
ROM only (varies
Ex: 45 degrees
Ex: 198.7 mV per degree
There are many types of devices to which you can connect. Biodex provides the “pin
outs” and leaves it up to the end user to make the interface cable. Because of the
popularity of this application, many companies have cables available for their devices.
Check with a particular interface device manufacturer. If not, make a cable to
communicate if the other device’s connections are known.
The connection is labeled REMOTE ACCESS on the back of the Biodex CDS cart. It is a DB-
15 female connector.
