Automated Operation
B-7
The Detailed Test results are displayed on the FlightHawk-AV’s measurement
display. See
Figure 8
.
When a VSWR test fails, the technician can view the trace and see exactly how
far the VSWR is above the test’s threshold.
To return to the previous Test Results Screen, tap (back button).
Figure 8 Detailed Test Results Screen
For information in interpreting the display see the following references:
"Measure Match Mode" on page 29
"Limit Line" on page 14
!"# $ !"#
!"# $ !"#
