SRP-E770III
4-3-4 Ethernet Communication Block Diagram
The printer supports the Ethernet. The Network type is 10/100 Base-T All in one type. (Auto detection)
4-3-5 USB Communication Block Diagram
The printer support the USB(Universal Serial Bus). The transfer type is the BULK.
Figure 4-5 USB2.0 Communication Block Diagram
Atmel
CPU
Device
USB
B type
Connector
D+, D-
Figure 4-4 Ethernet
Communication Block Diagram
