BIXOLON SRP-E770III - Lower Frame Block

SRP-E770III
5-2 Lower Frame Block
5-2-1 Lower Frame Block
Figure 5-3 Disassembly Frame Lower #1
1. Move the Guide hinge
①
.
2. Separate the Lower-Frame Assembly② from the Case-Upper Assembly③.
② Lower- Frame
Assembly
①
Guide hinge
③ Case-Upper
Assembly
Ver. 1.01
- 38 -
