Bizerba SC II 100 User Manual

Operating instructions SC II Device and operating controls
61429850113 en-US 35 / 107
Insert label roll
Open the side cover and printer cover
[}30].
Open the thermal print head [}33].
Remove the label roll from the take-up
pin
3
.
Pull the red peel-off unit
6
outwards.
Pull the backing paper off the unwinding
shaft
1
.
Pull 5 labels off the backing paper of the
new label roll.
Place the new label roll
4
on the take-
up pin
3
.
Insert the backing paper in accordance
with paper feed and attach it to the take-
up pin
1
. The backing paper must be
aligned to the flange
2
.
Press the red peel-off unit
6
inwards.
Turn the take-up pin
1
manually until
the first label is peeled off.
Close the thermal print head [}33].
Close the side cover and printer cover
[}30].
Illustration25: SC II 100 Label printer
5.4.4 Ticket roll
Run out of ticket paper
If the ticket roll is empty, the following status message appears: "Printer 1: end of paper"
The remaining paper is automatically rejected.
Menu setting
- Automatic paper infeed only with printer operating mode "Ticket" or "Label printout on
ticket". Select 5 3 2 2 4

Bizerba SC II 100 Specifications

General

Brand	Bizerba
Model	SC II 100
Category	Scales
Language	English
