BK Precision 2190D User Manual

23
Fine changes the resolution to small
steps between the coarse settings.
Probe
1X, 5X
10X, 50X
100X, 500X,
1000X
Set to match the type of probe you
are using to ensure correct vertical
readouts.
Next Page
Page 1/3
Press this button to enter the second
page menu
Table 3.4 – Channel Function Menu 2
Option
Setting
Instruction
Invert
on
off
Turn on invert function.
Turn off invert function.
Filter
Press this button to enter the
“Digital Filter menu”.
Next Page
Page 2/3
Press this button to enter the third
page menu.
Table 3.5 – Channel Function Menu 3
Option
Setting
Introduction
Unit
V
A
Set the scale unit to voltage
Set the scale unit to current.
Skew
-100 ns –
100ns
Set the skew time between two
channels.
Next Page
Page 3/3
Press this button to return to the
first page menu.
