97
Browse
• Use the knob to shift between the directories to choose Local (C:) or USB Device (0:).
Choose Browse, press the knob to open the current directory.
• Use the knob to switch between folder and files under the current directory. Choose
Browse, press the knob to open the subdirectory. Choose <up>, then choose Brower
or press the knob to return to the upper level directory.
5.2 File Type
Choose Store/Recall → File Type to select the desired file type. Available file types are State File
and Data File.
State File
Store the instrument state in internal or external memory in “*.xml” format. The state file
stored includes waveform parameters and modulation, sweep, burst parameters of two
channels and utility parameters.
Note: The 4050B series can only identify files of which filenames consist of English letters, numbers and
underscore. If other characters are used, the name may be displayed in the store and recall interface
with errors or not found at all.
