BK Precision 4054B User Manual

57
a. Press the Source softkey.
b. Press the Internal softkey to select an internal trigger.
The generator outputs a continuous sweep waveform when internal trigger is
selected. The default is “Internal”.
External Trigger
a. Press the Source softkey.
b. Press the External softkey to select an external trigger.
The generator uses the trigger signal input to the [Aux In/Out] connector at the rear
panel. A sweep will be generated once a TTL pulse with specified polarity is sent. To
set the CMOS pulse polarity refer to the Direction section at the end of this section.
Manual Trigger
a. Press the Source softkey.
b. Press the Manual softkey.
A sweep will be generated when the Trigger softkey is pressed.
7. After selecting the type of trigger and pressing the softkey to select it, the user will exit
the Trigger Source menu.
Trig out
8. In the menu of the Sweep function, press Trig Out.
9. Toggle the softkey On and the [Aux In/Out] connector at the rear panel will output the
trigger signal.
Figure 39 - Trigger Types
