BK Precision 4054B User Manual

80
Function
Menu
Description
CH1 Switch
CH1
Output the CH1 waveform.
CH1+CH2
Output the CH1+CH2 waveform.
CH2 Switch
CH2
Output the CH2 waveform.
CH1+CH2
Output the CH1+CH2 waveform.
Return
Save the current settings and exit the current
interface.
4.5 CH Copy/Coupling
Channel Copy
The generator supports a state and waveform copy function between its two channels. This
copies all parameters and states (including the channel output state) and arbitrary waveform
data from one channel to the other channel.
Figure 58 - Wave Combine Menu
Notes:
1. Combining with a Square waveform is not possible.
2. When the waveform combining function is enabled, the output impedance of the two channels
will be set to be the same as the currently operated channel.
