108

Example 6: Generate a DC Waveform

Generate a 3 V DC waveform.

⚫ Choose the DC waveform.

1. Press Waveforms →Page 1/2→ DC to choose the DC waveform.

⚫ Set the Offset.

1. Press Offset and choose Offset which will display in a blue color.

2. Input ‘3’ from the keyboard and choose the unit ‘Vdc’. The DC offset is set to 3 V.

When the DC offset is set, the waveform generated is shown in Figure 79.

Figure 78 - Generate a Noise Waveform
