3.3 Configure Waveform Output

Configure Waveform Shape

The instrument can generate many standard as well as arbitrary waveforms. There is a

dedicated waveform key on the front panel that will allow the user to select between different

waveform shapes to output, as listed in Table 4.

Waveforms

Sine

Square

Ramp

Pulse

Noise

Arbitrary

Figure 4 - Channel 2 Selected

Table 4 - Waveforms
