59
Direction
1. In the Sweep Function menu, press the Page 1/2 . softkey to access the second page of
Sweep Options.
2. Press the Direction softkey to toggle between the two options: Up and Down.
• Up: the generator will sweep from the Start frequency to the Stop frequency.
• Down: the generator will sweep from the Stop frequency to the Start frequency.
3.6 Configure Burst
The Burst function allows a specified number of periods of a waveform to be output (N-Cycle
mode) or the waveform can be gated by an external signal (Gated mode). Any waveform except
DC may be used as the carrier, with the limitation on the noise waveform in which only gated
burst function is supported.
Note: Sweep function is only available for sine, square, ramp, and arbitrary waveforms. It is not available for
pulse, noise, or DC waveforms.
