Example 3: Generate a Ramp Waveform
Generate a ramp waveform with 10 μs period, 100 mVpp amplitude, 20 mV DC offset, 45°
phase and 30% symmetry.
⚫ Set the Period.
1. Press Waveforms → Ramp → Frequency/Period and choose Period which will display in a
blue color.
2. Input ‘10’ from the keyboard and choose the unit ‘μs’. The period is set to 10 μs.
⚫ Set the Amplitude.
1. Press Amplitude/HighLevel to choose Amplitude which will display in a blue color.
2. Input ‘100’ from the keyboard and choose the unit ‘mVpp’. The amplitude is set to 100 mVpp.
⚫ Set the DC Offset.
1. Press Offset/LowLevel to choose Offset which will display in a blue color.
2. Input ‘20’ from the keyboard and choose the unit ‘mVdc’. The offset is set to 20 mV DC.
⚫ Set the Phase.
1. Press Phase to choose Phase which will display in a blue color.
2. Input ‘45’ from the keyboard and choose the unit ‘°’ (degrees). The phase is set to 45°.
⚫ Set the Symmetry.
1. Press Symmetry to choose Symmetry which will display in a blue color.
2. Input ‘30’ from the keyboard and choose the unit ‘30%’. The symmetry is set to 30%.
When the period, amplitude, offset, phase and symmetry are set, the waveform generated is
shown in Figure 76.
