13
Source
Selects modulating source.
AM Depth
Set the modulation depth.
Shape
Configures the modulating waveform shape.
AM Freq
Set the modulating waveform frequency. Frequency range:
1 mHz to 20 kHz (internal source only).
Sweep
Sweep Time
Configures the sweep time for sweep output.
StartFreq/CenterFReq
Configures the sweep start frequency or the center
frequency.
StopFreq/FreqSpan
Configures the sweep stop frequency or the frequency
span of the sweep output.
Source
Selects the sweep source: Internal, external or manual.
Trig Out
Enable/disable trigger out.
Type
Selects between linear or logarithmic sweep operations.
Direction
Selects the sweep direction.
Burst
Ncycle/Gated
Selects burst by number of cycles or selects external gated
burst.
Cycles/Infinite
Configures number of cycles for burst or infinite burst
(external source only).
Start Phase
Configures the start phase of the burst output.
Burst Period
Configures the burst period.
Source
Selects trigger source: Internal, External, Manual.
Trig Delay
Configures the delay of each burst.
Trig Out
Configures signal triggering on rising or falling edge.
Utility
System
Access system settings.
Test/Cal
Configure synchronization output with respect to either
channel 1 or 2.
Counter
Selects built-in counter function.
