CHAPTER 3: INSTALLATION
3.5.2 ALL LES1700 MODELS
The LES1700 models have an internal 802.11 WiFi adapter and come with an external WiFi antenna.
Before powering on the LES1700:
 Screw wireless antenna on to the WIFI (MAIN) SMA connector.
The LES1700 has a second WiFi antenna connector. This WIFI (AUX) connector can be used for diversity and requires an external antenna
(not included).
