CHAPTER 5: SECURITY APPLICATION
STEP 4: Send frames between PORT-3 and PORT-4, see test result.
FIGURE 5-14.
CLI COMMAND
access-list ace 5 ingress interface GigabitEthernet 1/3 policy 5 frametype etype smac 00-00-00-00-00-13 dmac
00-00-00-00-00-11
exit
interface GigabitEthernet 1/3
switchport trunk allowed vlan 4,5
switchport trunk vlan tag native
!
interface GigabitEthernet 1/4
switchport trunk allowed vlan 4,5
switchport trunk vlan tag native
exit
CASE 1H
Because the default ACL Rule of GE port is “Deny”, Queue Mapping action does not apply. We do not do this case.
CASE 1I
Because the default ACL Rule of GE port is “Deny”, CoS Marking action has no sense. We do not do this case.
