12 en | Introduction Digital Video Recorder
F01U | 1.0 | 2007.11 User Manual Bosch Security Systems
c Disc Tray (DVR-8L and DVR-16L only)
Insert a disc here.
d Channel Buttons
You can input a number with the channel buttons. You can also use the channel buttons for
sub-function with ALT button (The COPY, IRIS +, SET, CLEAR, MOVE and TOUR buttons of 8
channel DVR are used for subfunction without ALT button.).
• The LED in the button indicates the status as follows:
- Off: The current status is for live mode.
- Red: Recording mode.
Blinks when an event occurs.
• (1) OPEN: Opens or closes the disc tray (DVR-8L and DVR-16L only).
• (2) LOCK: Displays the lock menu to change the user type or disable the system
operation.
• (3) ZOOM - / (4) ZOOM +: Adjusts the zoom level of the PTZ camera.
• (5) LOG: Displays or removes the System Log List.
• (6) INFO: Displays or removes system information.
• (7) FOCUS - / (8) FOCUS +: Adjusts focus position of the PTZ camera.
• (9) COPY: Copies the recording data to an external device.
• (10) MARK: Sets the mark point for recording search. You can set the mark point during
the single channel playback of recorded data.
• (11) IRIS - / (12) IRIS +: Adjusts iris position of the PTZ camera.
• (13) SET: Registers the PTZ camera's preset position.
• (14) CLEAR: Deletes a memorized preset position of the PTZ camera.
• (15) MOVE: Moves the PTZ camera to the preset position.
• (16) TOUR: Tours all registered preset positions in the PTZ camera.
e Shuttle Ring: Fast forward or reverse picture search when the dial is rotated.
f JOG Dial: Allows a forward or reverse frame search.
In pause mode, plays recorded images frame by frame through rotation. Increases or
decreases the options value.
g ESC: Use to return to previous level or to exit menu system without saving.
h Playback Control Buttons
- X: Pauses playback.
- m: Reverse search the recorded images.
- bB: Playback or reverse playback of recorded images.
- M: Forward search the recorded images.
- x: Stops playback.
i Indicators
: Lights when the DVR is powered.
: Blinks when the HDD is accessed.
: Lights when the alarm is active.
: Lights when a network cable is connected.
j USB Port
Connect an external USB device for back up or playback.
k Remote Sensor
Point the remote control here.
l ALT
Activate if you use the Sub-function of the channel button.
