Application Example BTV 20.4A and SERCOS Interface
Fig.4-45: SERCOS connection
BTV 20.4 A with a SERCOS interface module (i.e. up to 8 axes).
Project Planning Manual | Rexroth MTA 200 Electric Drives
and Controls
| Bosch Rexroth AG 53/135
Machine Operator Terminal BTV 20.4A
