Ordering designation of as‐
sembled cables
Mating connector of the de‐
vice
Bosch Rexroth cable Design of the cable end
INS0540/K01
MN: 279 538
Fig.4-67: INS0540/K01
Profibus connector for self-as‐
sembly with termination
INS0541/K01
MN: 279 539
Fig.4-68: INS0541/K01
Profibus connector for self-as‐
sembly with termination
(mountable side by side)
Fig.4-69: Accessories MTS-R
Lockable floppy-disk flap
Furthermore, a accessories kit can be ordered for the BTV 20.4 in order to
backfit the device with a lockable floppy-disk flap: SUP-M01-BTV20
Fig.4-70: SUP-M01-BTV20, lockable floppy-disk flap
62/135 Bosch Rexroth AG | Electric Drives
and Controls
Rexroth MTA 200 | Project Planning Manual
Machine Operator Terminal BTV 20.4A
