REFUspeed RS51 Basic parameterization 7-11
DOK-RD500*-RS51*******-IB02-EN-P
Parame-
ter No.:
Name Description / explanation
selectable options
Factory setting
min ... max values
Pass
wor
d
85 = O RFG up
86 = O RFG down
87 = O RFG reached
88 = O setpoint reached
89 = O setpoint in tolerance
90 = O fmin limiting
91 = O fmax limiting
92 = O TEST selected
93 = O control line contactor
94 = O fact ≤ fmin
95 = O ALM sparking signal
96 = O ALM load limit
97 = O open mechanical brake
0461 Mode dig. output Supplementary parameter for P0875 for all output
functions
Output, direct 1
0 = output, direct
1 = output, inverted
0...1
0289 Fast stop, ramp-
down time
Supplementary parameter for “Ifaststop”. 5.000 sec 1
Ramp-down time for fast stop 0.000 ... 3200.000
sec
0739 Motpot cycl. time ext. Supplementary parameter for “I motp. faster” and “E
motp. slower”
0.90 sec 1
Step cycle time when energized via digital input 0.01 ... 5.00 sec
1210 ALM cycle time sen-
sitivity up / down
Supplementary parameter for “I ALM sensitivity up”
and “I ALM sensitivity down”
0.50 sec 1
Step cycle time when energized via digital input 0.05 ... 5.00 sec
1209 ALM step width sen-
sitivity up / down
Supplementary parameter for “I ALM sensitivity up”
and “I ALM sensitivity down”
0.02 % 1
Step cycle time when energized via digital input 0.01 ... 100.00 %
0756 Time, timer Supplementary parameter for “O motor rotating 1”.1.0sec 1
Time for the timer 0.0 ... 650.0 sec
0435.00 Fixed value for Dxxxx Supplementary parameter for “O motor rotating 1”.0.00% 1
Current threshold (100% = Irated motor) -199.99 ... 199.99
%
0757 Hysteresis x:xs Supplementary parameter for “O motor rotating 1”.1.00% 1
Hysteresis for current 0.00 ... 100.00 %
0759.00 Hysteresis x:xs Supplementary parameter for “O motor rotating 2”.1.00% 1
Hysteresis for frequency 0.00 ... 100.00 %
0759.01 Hysteresis x:xs Supplementary parameter for “O motor rotating 2”.1.00% 1
Hysteresis for current 0.00 ... 100.00 %
0435.01 Fixvalue for Dxxxx Supplementary parameter for “O motor rotating 2”.0.00% 1
Current threshold (100% = Irated motor) -199.99 ... 199.99
%
0760 Fixvalue xs input Supplementary parameter for “setpoint reached” and
“setpoint within the tolerance bandwidth”.
2.00 % 1
Tolerance value for the frequency 0.10 ... 100.00 %
0761 Hysteresis x:xs Supplementary parameter for “setpoint reached” and
“setpoint within the tolerance bandwidth”.
Hysteresis for frequency
1.00 %
0.00 ... 90.00 %
1
