1 695 600 091 2012-11-16| Robert Bosch GmbH
Menu navigation | WBE 4200 | 41 en
GLR
2)
ANG
LIN
Activate/Disactivate angular
width calibration (An6) or the
length measuring arm (Lin)
FST On
OFF
Activate/Disactivate the quick
measurement cycle
ILL* On
OFF
Internal illuminator activation/
deactivation
BRA* On
OFF
Electro-magnetic brake
activation/deactivation
1) Function only available with gauge arm for measuring rim width
fitted and activated.
*)Option not available for WBE 4200
NOTES FOR THE ASSISTANCE:
Here you are the settings belonging to the WBE 4200
version:
Left Display Right Display
POT On
ALU On
FLA OFF
PLR OFF
GLR Lin
FST On
ILL OFF
BRA OFF
5.2.1 Firmware updating procedure
The new generation of boards introduced by Sicam
works in Windows CE; this enables our research and
development department to constantly update the
machines, in order to resolve any programming errors
and to add functions to the machine, like translations in
different languages and special programmes.
i The updates are sent via PROGUSB.
i To use the device, see the manual specific.
i Repeat machine calibration after updating.
i Current software version can be seen on EDIS\
SOFTWARE\SYSTEMSW\WB ("WB" stands for the
wheel wheel balancing machine model designation)
or ask Technical Support.
5.3 Calibration
Press <MENU> until the notice <CAL> is shown and
then press <OPERATOR>.
R <MENU> - SET - CAL - <OPERATOR>
5.3.1 Flange calibration
Left Display Right Display Description
C-1
Memorization of the zero group
flange and shaft
C-2
Setting up of the wheel size and
memorization of the unbalance
5.3.2 Calibrating the electronic vernier caliper
Left Display
Right Display
Description
D-1 0 or higher
Calibration of the distance
potentiometer: position of rest
D-2 200
Calibration of the distance
potentiometer: position at 20cm
H-1 ex.: 15“
Calibration of the diameter
potentiometer
C-2
Setting up of the wheel size and
memorization of the unbalance
5.3.3 WBE 4200 calibration
Left Display
Right Display
Description
C-2
Setting up of the wheel size and
memorization of the unbalance
C-3
Setting up of the calibration
weight and launch with the weight
inside
C-4
Launch with the weight outside
C-5
Adjustment of the angle
