5.3.4 Auto-diagnosis
Press the <MENU> key until you see the word t5t and
then access the sub-menu by pressing the <USER> key
within 1.5 seconds.
R <MENU> - SEt - CAL - TST
Left Display
Right Display Description
MSR Press <RIM DISTANCE> /
<
RIM DIAMETER>to roll
down menu
ex.: 892
1° shown value:
tension measured in left pick-up
ex.: 1338
2° shown value: tension
measured in the right pick-u
es.: 180 ex.: 810
3° shown value: phase angle
difference
ex.: 2
4° value: Rounded off ratio
between the pick-ups
Left Display
Right Display Description
ENC
It shows the position of the
encoder from 0 to 255
Left Display
Right Display Description
SP
Speed in turn/min of the shaft
Left Display
Right Display Description
0 2048
Reading analog entry of the
external pick-up
Press <RIM DISTANCE> to
roll down menu
1 2048
Reading analog entry of the
internal pick-up
2 2048
Reading analog entry of the
enlarged internal pick-up
3 2048
Reading analog entry of the
enlarged external pick-up
4 500
Reading of the sensor of the
distance (no SBM125)
5 500
Reading of the sensor of the
width(no SBM125)
6 500
Reading of the sensor of the
diameter (no SBM125)
7
Non used
8
Non used
9
Non used
10
Non used
Left Display
Right Display Description
CNT Press <RIM DISTANCE> to
roll down menu
1 500
Overall launches (ex:1500)
6
Daily launches (since when the
balancing machine has been
turned on)
Left Display
Right Display Description
LED Press <RIM DISTANCE> to
roll down menu
Left Display
Right Display Description
TAR Press <RIM DISTANCE> to
roll down menu
Left Display
Right Display Description
I_0 Digital entries: press the <RIM
DISTANCE
> button to roll
down the menu
MAG on/oFF
ALUDATA® electromagnet test
FLA on/oFF
Test to the electro valve of the
pneumatic flange
BRA on/oFF
Checks the electro-magnetic
brake activation
0.UP on/oFF
Checks hoisting device
solenoid valve
R Ascent check
O.dU on/oFF
Checks hoisting device
solenoid valve
R Descent check
PFL on/oFF
Check the opening of the
pneumatic flange
PBR on/oFF
Checks the electro-magnetic
brake activation
INP on/oFF
State of the carter: OFF open,
ON closed
I.UP on/oFF
Lifter up button activation
control
I.DU on/oFF
Lifter down button activation
control
Left Display
Right Display Description
REL oFF
Start of the relative balancing
procedure
! NOTE: All the options are described in details on the
following pages.
