AirborneM2M™ User Guide
120
PHYSICAL & ENVIRONMENTAL APPROVALS
The device has passed the following primary physical and environmental tests. The test methods
referenced are defined in SAE J1455, August1994.
Table 47 - Mechanical Approvals
Test Reference Conditions
Temperature Range
(Operational)
Table 1B, Type 2b -40 to +85 °C
Temperature Range
(Non-Operational)
-40 to +125 °C
Humidity Sect 4.2.3
0-95% RH @ 38 °C condensing
Fig 4a – 8 hours active humidity cycle
Altitude Sect 4.8
Operational: 0-12,000ft (62 KPa absolute pressure)
Non-operational: 0-40,000ft (18.6 KPa absolute pressure)
Vibration* Sect 4.9
Operational: 2.4 Grms, 10-1K Hz, 1hr per axis
Non-operational: 5.2 Grms, 10-1K Hz, 1hr per axis
Shock* Sect 4.10 Operational: 20Gs Max, 11ms half-sine pulse
Product Drop* Sect 4.10.3.1 1m onto concrete, any face or corner, 1 drop
Packaging Drop* Sect 4.10.2.1
32 inches onto concrete on each face and corner.
Packaged in ‘for transit’ configuration.
* These tests were conducted with the module mounted in a suitable enclosure. See product
datasheets for additional approvals. Test reports are available from B+B SmartWorx. Contact Technical
Support for latest test documentation.
