AirborneM2M™ User Guide

ETHERNET ROUTING SETTINGS

URL /Configuration/Ethernet Routing Settings

Description Configures the firewall routing rules for the Ethernet interface.

Field CLI Command

Ethernet Routing Default

eth-route-default

Add rule [Button]

eth-route
