AirborneM2M™ User Guide
52
CONFIGURING FOR PEAP SECURITY
This security type is a very popular type for enterprise networks. Actual use of the security protocol requires
that the network is using a RADIUS server for device authentication. Depending on the security policies of
the network, this protocol supports authentication with and without a CA (Certification Authority) certificate.
The Airborne device supports PEAPv0 using both WPA (TKIP) and WPA2 (AES-CCMP) encryption. The
device will automatically use the most appropriate encryption type to obtain authentication to the WLAN.
Table 26 - Configuring for PEAP Security
Step Description
Navigation Bar
You will see a group of fields under the banner of WLAN
Parameters.
Feature Link
Select WLAN Security Settings
The wireless interface must be configured before
configuring the security for the network.
A page showing the range of security options and fields is
Select Wireless LAN Security Select PEAP from the drop down list.
Select EAP Identity Enter the RADIUS server account name provided by the
network administrator.
If a Windows domain server is being used for
authentication, the server domain must be included in the
EAP Ident field
Select EAP Password Enter the RADIUS server account password for the EAP
Ident.
Select EAP Phase 1 String Enter
Select EAP Phase 1 String Enter
Select CA Certificate Filename Enter the name of the Certificate Authority (CA) certificate
stored on the device.
Storing Certificates on the device is cover in section 15.5.
If the network security does not require the use of a CA
certificate, this field should be left blank.
Press Commit [Button] Saves changes to the device.
Optional
Reloads the WLAN Settings page. Select this if you have
further configuration options to change.
Optional
Press Restart [Button]
Restarts the device. After the device is rebooted, it will
attempt to authenticate to the configured network. As long
as the network is in range, the wireless interface will
connect.
If the network is using DHCP, then an IP address will be
assigned to the WLAN interface and IP connectivity is
possible over the WLAN network.
If the network is using static IP addresses, it will be
necessary to configure the network interface. See the next
Feature Link
Select Network Settings
The wireless interface is now configured. However, if the
WLAN network does not have a DHCP server available to
provide IP address, to the device, it necessary to assign a
static IP address to the wireless interface.
Selecting Network Settings will allow configuration of the
device with a static IP address. This is covered in section
To Next Page
