AirborneM2M™ User Guide
19
ELECTRICAL & RF SPECIFICATION
Table 8- Absolute Maximum Values1
Parameter Min. Max. Unit
Maximum Supply Voltage - Enterprise 4.5 5.5 VDC
Maximum Supply Voltage - Industrial 5.0 36 VDC
PoE 802.3af Class1 – Industrial (IN5xx8 models) 37 57 VDC
Power Dissipation 3.00 W
Operating Temperature Range -40 85
o
C
Storage Temperature -40 85
o
C
Note: 1. Values are absolute ratings, exceeding these values may cause permanent damage to the device.
Table 9 - RF Characteristics – 802.11a/b/g/n
Symbol Parameter Rate (Mb/s) Min.
Average
dBm / mW
Peak
dBm / mW
Units
P
OUTB
Transmit Power
Output 802.11b
11, 5.5, 2, 1 15.0 31.6 dBm
P
OUTG
Transmit Power
Output 802.11g
6, 9, 12, 18,
24, 36, 48, 54
12.6 18.2 dBm
P
OUTA
Transmit Power
Output 802.11a
6, 9, 12, 18,
24, 36, 48, 54
17.0 50.1 dBm
P
RSENB
Receive Sensitivity
802.11b
11 -86
dBm
1 -92
P
RSENG
Receive Sensitivity
802.11g
54 -72
dBm
36 -78
18 -84
6 -89
P
RSENA
Receive Sensitivity
802.11a
54 -74
dBm
36 -80
18 -86
6 -90
F
RANGEBG
Frequency Range 2412 2484 MHz
F
RANGEA
Frequency
Range 802.11a
4910
5150
70
4990
5350
5825
MHz
The transmit power is automatically controlled by the device for minimum power
consumption.
The transmit power at the antenna connector is listed in Table 9 above (±2dBm).
