AirborneM2M™ User Guide

ETHERNET DHCP CLIENTS

URL /Status/Ethernet DHCP Clients

Description Displays the IP address issued by the DHCP server to specific MAC addresses.

Field CLI Command

Displayed Page

eth-dhcp-clients
