AirborneM2M™ User Guide
31
10
Opening web page shows adapter status.
Links to the available configuration options are identified in the left hand menu. The top menu bar provides
access to different operations that can be performed by the AirborneM2M™ device.
See section 15.0 for a full description of how to use the web interface.
11
Using Express Setup:
If this is the first time you have configured the device, the Express Setup page will be displayed.
Please refer to section 16.0 to continue set-up of the device.
If this is not the first time, proceed to section to update configuration.
When the Reboot button is pressed, the unit will restart and install new settings. This may take 15-20 seconds.
Please refresh the web interface after the boot cycle has completed.
13
When configured correctly, the LED pattern should match the following:
ABDx-SE-IN5xxx No TCP Connection TCP Connection
COMM: Off Green
LINK : Green Green
POST: Green Green
POWER: Blue Blue
To use the adapter on the wireless network, address all traffic to the IP address of the wireless interface of the
ABDN-SE- IN54xx. This address is listed in the home page of the web interface.
