• Fibonacci tube: this guides the lament into the extruder without it breaking.
It ends at the tube connector.
• Hot-End: this is the part that melts the polymer lament. As this element is
more complicated, we will look at it in greater detail later on in this manual.
Figure 5.2 Interior of the extruder
Figure 5.3 Constituent parts of the extruder
Pulley
Extruder leverExtruder body
Extrudermotor
Fan
Fan and heat sink
Tube connector
Fibonacci
tube
Hot-End
Blower
