6
Disconnect the Fibonacci tube from the extruder by pressing down on the
connector and pulling the tube upwards.
7
Remove the blower using the 2.5 mm Allen key.
8
Remove the fan and heat sink using the 2.5 mm Allen key. The fan will remain
partially attached to the extruder, although the heat sink can be removed
completely.
