BradyPrinter i3300 28
Maintenance
Pre-maintenance Operations
3. Release the latch on the print head door [2] and swing open.
4. Release the ribbon cartridge latch [3] and lift the ribbon cartridge up and out.
5. Move yellow supply wiper [4] to the back.
6. Move yellow supply guides [5] to full-open.
7. Remove cartridge from the slots of the holder [6].
3
2
4
5
6
