88 Brocade FastIron X Series Chassis Hardware Installation Guide
53-1001723-02
Displaying chassis status and temperature readings
4
The show chassis display shows the following information.
TABLE 20 Chassis status and temperature information
This Field... Displays...
Chassis Type This field displays the chassis type. For example:
• FastIron SuperX
• FSX 800
• FSX 1600
• ANR-FSX 1600-PREM
ANR indicates that the chassis has Accoustic Noise Reduction. For more
information about the ANR chassis, refer to “FSX 1600 chassis” on page 9.
-PREM indicates that the device is a premium device (supports full Layer 2
switching and full Layer 3 multiprotocol routing).
Power
Power Supply Indicates whether a power supply is installed in the specified power supply slot and
the status of the power supply, which can be one of the following:
• OK – The power supply is functioning properly and supplying power to the
chassis and installed modules.
• Failed – The power supply is not functioning and is not supplying power to the
chassis and installed modules.
This field also indicates:
• the manufacturing part number
• whether the supply is AC or DC
• whether the supply is regular or POE.
On the FSX and FSX 800, Power Supply 1 is the left-most slot, and Power Supply 4 is
the right-most slot. These numbers assume you are facing the front of the chassis,
not the rear.
On the FSX 1600, Power Supply 1 is the top left-most slot, Power Supply 4 is the top
right-most slot, Power Supply 5 is the bottom left-most slot, and Power Supply 8 is
the right-most slot. These numbers assume you are facing the front of the chassis,
not the rear.
cont’d from previous page...
Slot 11 Temperature: 40.0 deg-C
Slot 12 Temperature: 46.0 deg-C
Slot 13 Temperature: 42.0 deg-C
Slot 14 Temperature: 44.5 deg-C
Slot 15 Temperature: 43.5 deg-C
Slot 16 Temperature: 40.0 deg-C
Slot 17 Temperature: 45.0 deg-C
Slot 18 Temperature: 41.5 deg-C
SF 1 Temperature: 40.5 deg-C
SF 2 Temperature: empty
Boot Prom MAC: 0012.f287.c900
