Brocade FastIron X Series Chassis Hardware Installation Guide 89
53-1001723-02
Displaying chassis status and temperature readings
4
Fans
Fan <number> For the FSX and FSX 800, this field displays formation about fans 1 through 6. Fan
locations are as follows:
Fan 1 – Left-most fan in bottom row
Fan 2 – Middle fan in bottom row
Fan 3 – Right-most fan in bottom row
Fan 4 – Left-most fan in top row
Fan 5 – Middle fan in top row
Fan 6 – Right-most fan in top row
For the FSX 1600, this field displays information about fans 1 and 2. Fan locations
are as follows:
Fan 1 – This is Fan A and is the right-most fan in the rear of the chassis.
Fan 2 – This is Fan B and is the right-most fan in the rear of the chassis.
<Fan status> The status of a fan can be one of the following:
OK – The fan is functioning properly and is keeping the temperature of each
module within an acceptable temperature range.
Failed – The fan is not functioning properly or the fan control module cannot
control the fan.
Speed <Operating mode> The operating mode of a fan can be one of the following:
Auto (automatic) – This is the default
Manual
<Current fan speed> The fan speed for the FSX and FSX 800 can be one of the following:
1 (low) – The fan is functioning at 25 percent of capacity.
2 (medium-low) – The fan is functioning at 37 percent of capacity.
3 (medium) – The fan is functioning at 50 percent of capacity.
4 (high) – The fan is functioning at 100 percent of capacity.
The current fan speed is shown in double brackets.
Temperature Readings
Fan controlled temperature The FSX displays the temperature reading of the management and interface
modules:
Rule 1/2 – The temperature reading of the management module.
Rule 2/2 – This field displays the highest temperature reading of all the
interface modules.
The FSX 800 and FSX 1600 display the temperature reading of the management,
interface, and switch fabric modules:
Rule 1/3 – The highest temperature reading of the management module or
modules.
Rule 2/3 – The highest temperature reading of all the interface modules.
Rule 3/3 – The highest temperature reading of the switch fabric modules.
TABLE 20 Chassis status and temperature information (Continued)
This Field... Displays...
