Brocade FastIron X Series Chassis Hardware Installation Guide 181
53-1001723-02
Upgrade kit contents
A
FIGURE 73 DIP key insertion for the IPv4 2-port 10-GbE management modules (SX-FI2XGMR4)
Rear
Port Connectors
CAUTION: PIN 1
MUST GO HERE!
If you accidentally insert
the upgrade DIP backwards,
the device will not work and
may be damaged when you
power it on.
DIP key
for upgrade
Pin 1
U63
