Hardware features
1
Figure 6 shows the chassis slots into which you can install the various modules and power
supplies.
FIGURE 6 FSX 1600 chassis slots
1Interface slot 1
2Interface slot 2
3Interface slot 3
4Interface slot 4
5Interface slot 5
6Interface slot 6
7Interface slot 7
AC OKDC OK ALM
EJECT SYS
AC OKDC OK ALM
EJECT SYS
Pwr
Active
Pwr
Active
13579 1119 13 15 17
21
12
20
14 16 18
246810
