Brocade Communications Systems FastIron X Series Hardware Installation Guide

Brocade FastIron X Series Chassis Hardware Installation Guide 13
53-1001723-02
Hardware features
1
Compared to the FSX 1600, the FSX 1600-ANR has improved, redirected airflow, better thermal
dissipation, and reduced acoustic noise. The front of the FSX 1600-ANR chassis is identical to the
FSX 1600 and both chassis use the same switch fabric, management and interface modules, and
power supplies. Figure 7 shows the front of the chassis, including a partial view of the ANR kit,
which is behind the chassis.
FIGURE 7 FSX 1600-ANR chassis front
1 ANR kit on rear of chassis
1
